Parameter Set Antidepressants 1/EXTENDED for automated sample preparation on Chromsystems MassSTAR
CE-IVD compliant automation on Chromsystems MassSTAR
Encompasses 13 analytes
3PLUS1® Multilevel Calibrator Set and MassCheck® controls
Part of the continuously extended MassTox® TDM Series A
Citalopram
N-Desmethylcitalopram
Duloxetine
Fluoxetine
Desmethylfluoxetine
Fluvoxamine
Mirtazapine
N-Desmethylmirtazapine
Paroxetine
Sertraline
N-Desmethylsertraline
Venlafaxine
O-Desmethylvenlafaxine
Clinical relevance
This parameter set allows the quantitative determination of citalopram (as sum of S- and R-citalopram), N-desmethylcitalopram, duloxetine, fluoxetine, desmethylfluoxetine, fluvoxamine, mirtazapine, N-desmethylmirtazapine, paroxetine, sertraline, N-desmethylsertraline, venlafaxine and O-desmethyl-venlafaxine in human serum or plasma samples via liquid chromatography mass spectrometry (LC-MS/MS).
It is intended as a therapeutic drug monitoring test, medically indicated for patients treated with one or more of the antidepressant drugs listed above.
MassTox® TDM Series A
The MassTox® TDM Series A is a modular system that enables the determination of 200 analytes without changing column or mobile phases, thereby minimising the workload in the laboratory.
It consists of 3 parts:
• MassTox® TDM Basic Kit A
• Specific MassTox® TDM Parameter Set (13 different parameter sets available)
• Analytical column MassTox® TDM MasterColumn® A
More information about MassTox® TDM Series A
MassSTAR
For this parameter set Chromsystems offers a CE-IVD compliant workflow method using the MassSTAR to automate the sample preparation.
More information about MassSTAR
Detailed performance evaluation data can be found in the appendices of the instruction manual.
| Method of Analysis | LC-MS/MS |
|---|---|
| Please note | The information listed here, including the sample preparation, is not sufficient for using the product. Please read the information provided in the instruction manual, which includes detailed information on limitations associated with the use of the product in line with its intended purpose. Detailed performance evaluation data can be found in the appendices of the instruction manual. |
| Lower and Upper Limit of Quantitation | Citalopram: 2.00 – 600 µg/l For the values of all analytes please refer to the instruction manual. Different systems might show different performance data. |
| Specimen | Serum/Plasma |
| Sample Preparation | The information on the sample preparation presented here is not sufficient for use in the laboratory. For a detailed step by step description, please refer to the instruction manual. Automated Sample Preparation * Ready to use automation routine provided with the installation by Chromsystems. |
| Run Time | 3.0 min |
| Injection Volume | 5 – 40 µl (mass spectrometer dependent) |
| Flow Rate | 0.6 ml/min |
| Column Temperature | +20 to +25 °C |
| Gradient | binary |
| Ionisation | ESI positive |
| MS/MS Mode | MRM |
| Parameters | Citalopram, Desmethylfluoxetine, Duloxetine, Fluoxetine, Fluvoxamine, Mirtazapine, N-Desmethylcitalopram, N-Desmethylmirtazapine, N-Desmethylsertraline, O-Desmethylvenlafaxine, Paroxetine, Sertraline, Venlafaxine |
92713/XT MassTox® TDM Parameter Set Antidepressants 1/EXTENDED
for automated sample preparation on Chromsystems MassSTAR
|
Order No. 92711 |
MassTox® TDM Basic Kit A for automated sample preparation on Chromsystems MassSTAR components (Quantities in kit) |
| 92001 | Mobile Phase 1, 1000 ml (3x) |
| 92002 | Mobile Phase 2, 1000 ml (3x) |
| 92003 | Precipitation Reagent, 50 ml (5x) |
| 92005 | Extraction Buffer, 5 ml (5x) |
| 92007 | Dilution Buffer 1, 50 ml (5x) |
| 92008 | Dilution Buffer 2, 50 ml (5x) |
| 92009 | Rinsing Solution, 1000 ml (2x) |
| 92056 | 96 Deep Well Plates, 8 pcs. (3x) |
| 92059 | Pierceable Adhesive Seals, 3 pcs. (4x) |
| 33006 | Reaction Vials, transparent, 1.5 ml, 100 pcs. (1x) |
| 92913/XT | MassTox® TDM Parameter Set Antidepressants 1/EXTENDED components |
| 92029/XT | 3PLUS1® Multilevel Plasma Calibrator Set Antidepressants 1/EXTENDED (lyoph.), 4 x 1 ml |
| 0214/XT | MassCheck® Antidepressants 1/EXTENDED Plasma Control, Level I (lyoph.), 5 x 1 ml |
| 0215/XT | MassCheck® Antidepressants 1/EXTENDED Plasma Control, Level II (lyoph.), 5 x 1 ml |
| 92046/AN1/XT | Internal Standard Set Antidepressants 1/EXTENDED and Neuroleptics 1/EXTENDED, consisting of: Internal Standard Mix, 4 x 1 ml (lyoph.) Reconstitution Buffer, 5 ml |
| Order No. | Required components (not included in the kit or the parameter set) |
| 92110 | MassTox® TDM MasterColumn® A, equilibrated, with test chromatogram, 1 pc. |
| C5235905 | High Vol. CO-RE tips, with filter, 1000 µl, 3840 pcs. |
| C5235903 | Standard Vol. CO-RE tips, with filter, 300 µl, 5760 pcs. |
| 92016/A1/XT | Tuning Mix Antidepressants 1/EXTENDED (Analytes and Internal Standards), 1 ml |
| Order No. | Lab equipment |
| 15070 | Stainless Steel Prefilter Housing, 1 pc. |
| 15071 | Stainless Steel Prefilter, 0.5 μm, 5 pcs. |
| 33006 | Reaction Vials, transparent, 1.5 ml, 100 pcs. |
-
3PLUS1® Multilevel Plasma Calibrator Set Antidepressants 1/EXTENDEDOrder no.: 92029/XTMassTox® TDM Series A Antidepressants 1/EXTENDED in Serum/Plasma – LC-MS/MS -
MassCheck® Antidepressants 1/EXTENDED Plasma ControlsOrder no.: 0213/XT; 0214/XT; 0215/XTMassTox® TDM Series A Antidepressants 1/EXTENDED in Serum/Plasma – LC-MS/MS -
Internal Standard Set Antidepressants 1/EXTENDED and Neuroleptics 1/EXTENDEDOrder no.: 92046/AN1/XTComponent of the Parameter Sets Antidepressants 1/EXTENDED and Neuroleptics 1/EXTENDED, available separately
-
MassTox® TDM MasterColumn® AOrder no.: 92110Analytical column for MassTox® TDM Series A - LC-MS/MS
-
Basic Kit A for automated sample preparation on Chromsystems MassSTAROrder no.: 92711CE-IVD compliant automation on Chromsystems MassSTAR
Part of the MassTox® TDM Series A
Modular system for therapeutic drug monitoring
Provides all components required for sample prep and all mobile phases -
Tuning Mix Antidepressants 1/EXTENDEDOrder no.: 92016/A1/XTTuning Mix for the Parameter Set Antidepressants 1/EXTENDED - LC-MS/MS
-
3PLUS1® Multilevel Plasma Calibrator Set Antidepressants 1/EXTENDEDOrder no.: 92029/XTMassTox® TDM Series A Antidepressants 1/EXTENDED in Serum/Plasma – LC-MS/MS
-
MassCheck® Antidepressants 1/EXTENDED Plasma ControlsOrder no.: 0213/XT; 0214/XT; 0215/XTMassTox® TDM Series A Antidepressants 1/EXTENDED in Serum/Plasma – LC-MS/MS
