MassCheck® Amino Acids, Acylcarnitines, Succinylacetone Dried Blood Spot Controls

Order No.: 0191/0192/0193
Parameters:
Acylcarnitines & free Carnitine, Alanine, Amino Acids, Arginine, Aspartic Acid, C0-Carnitine, C10-Carnitine, C12-Carnitine, C14-Carnitine, C16-Carnitine, C18-Carnitine, C2-Carnitine, C3-Carnitine, C4-Carnitine, C5-Carnitine, C5DC-Carnitine, C6-Carnitine, C8-Carnitine, Citrulline, Glutamic Acid, Glycine, Leucine, Methionine, Ornithine, Phenylalanine, Proline, Succinylacetone, Tyrosine, Valine
MassChrom® Amino Acids and Acylcarnitines from Dried Blood – LC-MS/MS
Grouped product items
Product Name Qty
MassCheck® Amino Acids, Acylcarnitines, Succinylacetone Dried Blood Spot Control, Level I
Order No.: 0192
MassCheck® Amino Acids, Acylcarnitines, Succinylacetone Dried Blood Spot Control, Level II
Order No.: 0193
MassCheck® Amino Acids, Acylcarnitines, Succinylacetone Dried Blood Spot Control, Bi-Level (I + II)
Order No.: 0191
Amino Acids and Succinylacetone Acylcarnitines and free Carnitine
Alanine Free Carnitine
Arginine C2-Carnitine
Aspartic acid C3-Carnitine
Citrulline C4-Carnitine
Glutamic acid C5-Carnitine
Glycine C5DC-Carnitine
Leucine C6-Carnitine
Methionine C8-Carnitine
Ornithine C10-Carnitine
Phenylalanine C12-Carnitine
Proline C14-Carnitine
Tyrosine C16-Carnitine
Valine C18-Carnitine
Succinylacetone (included in the Upgrade Set 57111)

MassCheck® Amino Acids, Acylcarnitines, Succinylacetone Dried Blood Spot Controls

For MassChrom® Amino Acids and Acylcarnitines from Dried Blood by LC-MS/MS (55000, 55000/F)
For MassChrom® Amino Acids and Acylcarnitines from Dried Blood/Non Derivatised by LC-MS/MS (57000, 57000/F)

0191 MassCheck® Amino Acids, Acylcarnitines, Succinylacetone Dried Blood Spot Control, Bi-Level (I + II), 2 x 3 spots
0192 MassCheck® Amino Acids, Acylcarnitines, Succinylacetone Dried Blood Spot Control, Level I, 1 x 3 spots
0193 MassCheck® Amino Acids, Acylcarnitines, Succinylacetone Dried Blood Spot Control, Level II, 1 x 3 spots

These control materials from Chromsystems are based on human whole blood and should be used according to the instruction manual. They are designed to monitor the accuracy and precision of analytical procedures in clinical diagnostics for the semi-quantitative determination of amino acids, acylcarnitines and succinylacetone in dried blood. While following the instructions the controls should be handled and measured in the same manner as a patient specimen.





More Information
Concentrations

Please note: Concentration values shown here are typical. For lot specific concentration values please refer to the product insert supplied with the materials. The product inserts can also be requested from us directly or downloaded from our website after login.

SubstanceUnitValue Level IRange Level IValue Level IIRange Level II
Succinylacetone µmol/l 2.02 1.22-2.81 5.62 3.56-7.68
Alanine µmol/l 417 192-642 715 314-1116
Arginine µmol/l 55 20-89 159 82-237
Aspartic acid µmol/l 103 66-140 251 166-336
Citrulline µmol/l 58 41-74 254 187-321
Glutamic acid µmol/l 450 290-611 792 545-1039
Glycine µmol/l 357 260-455 1026 721-1331
Leucine µmol/l 207 114-300 556 369-742
Methionine µmol/l 46 14-78 197 79-315
Ornithine µmol/l 195 115-276 448 281-615
Phenylalanine µmol/l 110 70-150 477 294-660
Prolin µmol/l 296 218-375 822 504-1140
Tyrosine µmol/l 152 103-201 522 358-686
Valine µmol/l 185 116-253 437 286-587
C0-Carnitine µmol/l 45.2 25.3-65.1 112 69.6-154
C2-Carnitine µmol/l 26.0 17.8-34.2 71.8 44.4-99.1
C3-Carnitine µmol/l 4.58 2.64-6.52 13.4 8.70-18.1
C4-Carnitine µmol/l 0.86 0.40-1.32 3.87 2.26-5.48
C5-Carnitine µmol/l 0.48 0.25-0.71 1.99 1.13-2.86
C5DC-Carnitine µmol/l 0.58 0.14-1.01 2.63 1.21-4.04
C6-Carnitine µmol/l 0.44 0.26-0.62 2.01 1.28-2.73
C8-Carnitine µmol/l 0.46 0.25-0.67 2.13 1.31-2.96
C10-Carnitine µmol/l 0.52 0.31-0.73 2.20 1.21-3.20
C12-Carnitine µmol/l 0.48 0.21-0.75 2.17 1.42-2.92
C14-Carnitine µmol/l 0.55 0.28-0.82 2.41 1.43-3.38
C16-Carnitine µmol/l 4.10 2.49-5.71 11.5 7.04-15.9
C18-Carnitine µmol/l 2.31 1.28-3.33 8.18 4.42-11.9
Method of Analysis LC-MS/MS
Parameters Acylcarnitines & free Carnitine, Alanine, Amino Acids, Arginine, Aspartic Acid, C0-Carnitine, C10-Carnitine, C12-Carnitine, C14-Carnitine, C16-Carnitine, C18-Carnitine, C2-Carnitine, C3-Carnitine, C4-Carnitine, C5-Carnitine, C5DC-Carnitine, C6-Carnitine, C8-Carnitine, Citrulline, Glutamic Acid, Glycine, Leucine, Methionine, Ornithine, Phenylalanine, Proline, Succinylacetone, Tyrosine, Valine

Download of Product Information Leaflets
For logged-in customers the product information leaflets for calibrators, controls, internal standards and tuning mixes can be downloaded from the downloadcenter.


Download of all other documents
In the below section logged-in customers can download various documents such as instruction manuals, safety data sheets, traceability chains for calibrators, and external quality assessments.
These documents can also be downloaded from the downloadcenter.

As a customer please login or register to gain full access.
